PRODUCTS: FIRE PUMP SYSTEMS

Flows UP TO 1500 GPM
Automatic Packaged Fire Pump Systems

Our Quality

We import pumps from companies certified to ISO 9001 by TUV, Germany and LPCB, UK . We are dedicated to our customers satisfaction.

EXCEL SERIES END SUCTION PUMP COUPLED WITH DIESEL ENGINE

Technical Data

Applications

• Fire Fighting and Hose Reel System
• Sprinkler System
• Deluge System
• Foam System
• Hydrant System

BARE SHAFT FIRE PUMP

Specifications

• Volute type, axial inlet, single stage centrifugal pumps.
• Suction & discharge flanges conforming to PN16.
• Impellers are single suction, enclosed type.
• Axial thrust balanced by back steel ring and balancing holes.
• Pump shaft supported by two heavy duty 6300 Series bearings.

Standard Productions

• Casing material: cast iron; operating pressure: 12 Bars.
• Impellers: high-grade cast iron; impeller nut: brass.
• No casing wear rings at standard EXCEL production; sufficient material for repair wear rings.
• Shafts: C–1040 grade carbon steel; shaft sleeve not used at EXCEL version; shaft near stuffing box coated with hard chromium.
• Four rings of PTFE braid soft packing with a lantern ring after the first ring.
• Glands: bronze; gland studs and nuts: stainless steel.
• Bearings: oil lubricated with oil seals; oil level eye, filling and drain plugs made of plastic.
• Casing gasket: O-ring made of Nitride Rubber.

Fire Pump Controllers

Fire pump controllers automatically/manual control the electric main pump (duty), pressure drop (minor) make-up pump (jockey), and standby diesel pump. The diesel pump meets water demand in power failure conditions. Controllers include automatic circuits to start the diesel pump during pressure drops or power failure, with optional custom modifications.

Salient Features

• Dry run protection (for pumps above 100 GPM)
• Continuous duty rated components/accessories
• Trusted brand components/accessories
• DOL / Star Delta starter circuit
• Different mounting styles
• Strong, reliable, and elegant design
• NFPA/IP standard model on request
• Low maintenance cost and easily available spare parts
• Standard cable marking for easy maintenance
• Versatile circuit for custom modifications
• Automatic or manual operation
• Compatible with remote signaling/monitoring (BMS or FACP)
• Fault or fire alarm (optional)
• Electronic battery charger (current sensing)
• Lamp test facility (optional)
• Fault trip facility other than dry run (optional)
• Special Y/inter-locking
• Crank protection circuit for diesel engine
• Delayed start for fire signal (optional)
• Capacity range: 10 GPM – 2500 GPM, 1.3 HP – 300 HP
• Low pressure cut-off (timer based) (optional)
